How to Resolve These Seven Error Codes on Your Nest Thermostat

Using a Nest thermostat is one of the most convenient ways to optimize the daily schedule of your comfort system. This smart thermostat can learn your preferences and automatically make adjustments. But as you can expect, it won’t work properly or at all if you see an error code on the display. The specific error code offers useful information about the source of the problem, something a knowledgeable technician can use to present solutions that much quicker.

Listed below are seven of the most common error codes you may discover on your Nest thermostat. We’ll explain the basics of each error code on top of how you might address it and the projected cost to do so. Remember that while the costs will ultimately depend on the specific Nest model, you can anticipate paying between $75-$200 for repairs. This should include things like travel and labor costs on top of any specific hardware necessary to complete repairs.

e298 – Critical

This critical error code is limited to the latest models of the Nest thermostat and appears when the power is detached from the system. As this is a critical power error, the thermostat will switch to the backup battery system. The error message will remain on display until the issue is fixed.

Losing power to your Nest thermostat can be for several reasons. The wiring could have disconnected or become damaged, or a disconnection might have occurred further along in your home’s electrical system. This might be the circuit breaker, fuse box or system switch. A certified technician should inspect electrical connections and wiring until they uncover the root of the problem.

e294 – Critical

Critical error code e294 is displayed when your Nest thermostat’s wiring has to be reconfigured. More specifically, you’ll need the technician to reconfigure the R wire. They’ll first perform a factory reset of your thermostat to ensure it’s not merely a software issue. If that doesn’t work, they’ll review the wiring diagram of the thermostat and begin looking at connectors.

They’ll shut off the power and progressively inspect each wire, ensuring they are fully inserted into the connector with the proper amount of uncovered copper. After they pinpoint the damaged connector, it can be swapped for a new one.

e195 – Critical

This critical error code can surface when the weather outside is especially hot. The HVAC system can break down and stop sending power to your Nest thermostat. When this problem lingers, the backup battery in your thermostat drains and the thermostat will subsequently turn off. Assuming the breakers are on, you can examine a few other places before calling a professional technician.

Because this error can drain your thermostat’s battery, the first step could be providing enough power to find out if this specific error code is what you’re facing. You can separate the thermostat from its base and provide power with a USB cable. Assuming it presents error code 195, you should continue to visually examine components such as the wiring as well as your air conditioner’s air filter or drainage system. If you can’t uncover anything wrong with these components, it will probably be best to call a pro.

e103 – Critical

Another critical error code, e103 signifies an electrical problem with your Nest thermostat. More specifically, e103 will refer to an overcurrent problem, which means the wiring is receiving more power than needed. This can stem from the breaker box, an error from the control board or thanks to a faulty connection in the thermostat. The technician can carefully inspect and test the Nest’s electrical system to determine where the power is surging or why the thermostat believes there’s an overcurrent problem.

n260

Although this error code isn’t critical, it could still keep you from using the Nest thermostat like normal. Error code n260 concerns the lack of a C wire or Nest Power Connector, as missing one can block your Nest from getting sufficient power. You can examine the Nest’s C connector for the presence of a C wire and modify the wiring itself if there is. If not, you’ll need a Nest Power Connector.

Due to installation of a Nest Power Connector, you might notice error code E297 show up. This can be resolved by updating your thermostat in Settings -> Software -> Update. If the Power Connector was already installed, you’ll instead have to update the wiring info in the app from Settings -> Thermostat -> Wiring -> Update wiring.

e104 – Critical

Just like error code e103, e104 is a critical error stemming from an overcurrent. If excessive power is sent through the Nest’s wiring, it can damage internal components and may even be a fire hazard. If you notice this error code show up on your Nest thermostat and want to take steps to prevent electrical damage, it’s suggested to switch the power off as soon as possible. You can then get in touch with a professional technician with the appropriate experience identifying and fixing electrical damage.

e73 – Critical

When your thermostat displays error code e73, it signifies that the Rc wire is not receiving power.

This will sometimes be as straightforward as the breaker being turned off, but it may also be something with the wiring. After shutting off the power to your HVAC system and thermostat, you can visually inspect the wires to make sure they’re not loose or damaged. If nothing seems to be out of place, it’s best to speak with a local professional.
